PLATE MOUNTING SLEEVES

For CI Flexo & Narrow Web Presses


VINSLEEVE: “NexGen”

With the rising demand of CI Wide Web Press and Narrow Web Label Presses, Vintex has developed “Plate Mounting Sleeves” on which Polymer Plate or Elastomer Plate can be mounted.

These Sleeves has been designed keeping in Mind the key features like

  1. Cost Effective Sleeve Technology
  2. Light in Weight
  3. Tuff Rubber Surface to give excellent Print Result.
  4. Resistance to Solvents and Inks
  5. Highly Durable
  6. Consistent Surface across and Along the length/ Dimensional stability .

NEXGEN Sleeves are available in following versions:

  1. NEXGEN: Thin
  2. NEXGEN: Hard
  3. NEXGEN: Plus
NEXGEN : THIN

Plate Mounting Sleeves used to mount Plate with Double Sided Tape

Being a Thin Sleeve , it is used to meet the smallest Print Repeat either on a mandrel or Adopter Sleeve or Bridge.

Available in : Length: upto 2000mm
Thickness: 0.5mm- 1mm

Color: Plain White

NEXGEN: HARD

This Plate Mounting Sleeve is covered with Light Weight Compound with a Compressible Hard Layer, which gives excellent print result and is compatible to solvent and Inks used in printing.

Available in: Length : 2000mm
Thickness From: 2mm-15mm
Color: Black

NEXGEN: PLUS

This special Plate Mounting Sleeve comprises of a compressible layer between Fibre and Hard Rubber Coating which gives Optimum Print Quality screen and Half Tones print results.

The speciality of this sleeve is that, it is lighter in weight despite having high thickness of Coating on it. This sleeve is available with Metal Notch.

Available in: Length upto: 2000mm Thickness from: 16mm-100mm
Color: Green

Comparison Chart of NEXGEN Sleeves

SPECIFICATIONS

NEXGEN: Thin

NEXGEN: Hard

NEXGEN: Plus

1 X Zero axial Line

yes

yes

Yes

Hardness

90 Shore D

85 Shore D

90 Shore D

Thickness Available

0.5mm-1.5mm

2mm-15mm

16mm-100mm

No of Layers

——-

2

3 Layer

Compressible Layer

No

No

Yes

Notch

Direct Slot

Direct Slot / Plastic Notch

Metal Notch

Color Code

Plain White

Black

Green
